| General Information | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 1000 | 1100 |
| Power Rating (kW) | 800 | 880 |
| Frequency (Hz) | 50 | |
| Engine Model | KTA38-G5 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (Customizable) | |
| Fuel Tank Operating Time | ≥ 8 hours @ 75% load | |
PRP (Prime Power): Available for unlimited annual hours in variable load applications according to GB/T2820-97. Includes 10% overload capability for 1 hour within 12-hour operation.
ESP (Emergency Standby Power): For emergency power supply during utility interruptions. No overload, utility parallel, or negotiated outage operation capability.
| Model | BC1100 (Open Type) | BC1100S (Silent Type) |
|---|---|---|
| Length (mm) | 4300 | 5600 |
| Width (mm) | 1750 | 2200 |
| Height (mm) | 3125 | 2500 |
| Tank Capacity (L) | 1840 | 1840 |
| Engine Model & Manufacturer | KTA38-G5 (Cummins) |
| Number of Cylinders | 12 |
| Cylinder Arrangement | In-line |
| Cycle | Four Stroke |
| Aspiration | Turbocharged, Aftercooled |
| Bore x Stroke | 159 x 159 mm |
| Displacement | 38 L |
| Compression Ratio | 13.9:1 |
| Fuel System | Cummins PT |
| Cooling System | Force Water Cooling Cycle |
| Total Lubrication System Capacity | 40.0 L |
| Coolant Capacity (Engine Only) | 32.7 L |
| Fuel Consumption @ 100% Load | 202 g/kWh @1500 rpm |
| Alternator Brand | BOBIG |
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-404E |
| Alternator Rated Power | 800kW/1000kVA |
| Rated Voltage | 230V/400V |
| Rated Frequency | 50Hz |
| Connecting Type | 3 Phase and 4 Wire |
| Number of Bearings | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H class |
| Voltage Regulation, Steady State | ≤±1% |
BOBIG products include a one-year or 1000-hour warranty (whichever comes first) from ex-factory date. Includes free replacement of easy-damageable spare parts due to production or material quality issues. Professional 24/7 after-sales support with technical assistance, maintenance, and repair services.
