| General Information | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 5 | 6 |
| Power Rating (kW) | 4 | 4 |
| Frequency (Hz) | 50 | |
| Engine Model | 3TNM68-GGE | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (According to customer requirements) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Dimension and Weight | Open Type (BYN6) | Silent Type (BYN6S) |
|---|---|---|
| Length (L) mm | 1400 | 1750 |
| Width (W) mm | 610 | 850 |
| Height (H) mm | 1130 | 1030 |
| Tank Capacity (L) | 9 | 9 |
| Engine Model & Manufacturer | 3TNM68-GGE (YANMAR) |
|---|---|
| Engine Model | 3TNM68-GGE |
| Engine Type | 4 cycle, Inline, Water-cooled Diesel |
| No. of Cylinders - Bore×Stroke(mm) | 3-φ68×72 |
| Combustion System | Indirect Injection |
| Compression Ratio | 23.5 |
| Displacement (liter) | 0.784 |
| Rated Output | kW(PS): 6.1(8.3)/7.3(9.9) min⁻¹: 1500/1800 |
| Continuous Rating | kW(PS): 5.5(7.5)/6.6(9) min⁻¹: 1500/1800 |
| Specific Fuel Consumption | g/kW-h(g/PS-h): max.265(195) (at rated output) min⁻¹: 1800 |
| Standard Ambient Condition | 25℃, 750mmHg, 30% |
| Engine Speed at No Load | Max.(min⁻¹): 1925(+25/-25) Min.(min⁻¹): 1500(+25/-25) |
| Governor Type | Centrifugal-all speed governor |
| Temporary(%) | max.10 (load 100%→0%) |
| Permanent(%) | max.5 (load 100%→0%) |
| Recovery Time(sec) | max.5 (load 100%→0%) |
| Stability(min⁻¹) | max.30 (load 100%→0%) |
| Firing Order | 1-3-2-1 (order from F.W.) |
| Direction of Rotation | Counterclockwise (viewed from F.W.) |
| Engine Dry Weight(kg) | approx.104 |
| Fuel Injection Timing(deg) | FIR16(+1/-1) |
| Fuel Type | Diesel oil |
| Fuel Injection Pump | B in-Line(MC), Yanmar made |
| Fuel Injection Nozzle | Hole type |
| Fuel Filter | Paper element |
| Alternator Brand | BOBIG |
|---|---|
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-164A |
| Alternator Rated Power | 4kw/5kva |
| Rated Voltage (V) | 230v/400v |
| Rated Frequency | 50hz |
| Connecting Type | 3 Phase and 4 W |
| Number of Bearing | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H class |
| Telephone Influence Factor (TIF) | ≤50 |
| THF | ≤2% |
| Voltage Regulation, Steady State | ≤±1% |
| Transient State Voltage | ≤-15%～+20% |
