| General Information | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 13 | 14 |
| Power Rating (kW) | 10 | 11 |
| Frequency (Hz) | 50 | |
| Engine Model | 3TNV88-GGE | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (According to customer requirements) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Dimension and Weight | Open Type BYN14 | Silent Type BYN14S |
|---|---|---|
| Length (L) mm | 1400 | 1750 |
| Width (W) mm | 610 | 850 |
| Height (H) mm | 1130 | 1030 |
| Tank Capacity (L) | 23 | 23 |
| Engine Model & Manufacturer | 3TNV88-GGE (YANMAR) |
|---|---|
| Engine Type | 4 cycle, Inline, Water-cooled Diesel |
| No. of Cylinders - Bore × Stroke (mm) | 3-φ88×90 |
| Combustion System | Direct Injection |
| Compression Ratio | 19.1 |
| Displacement (liter) | 1.642 |
| Rated Output kW(PS)/min-1 | 13.2(17.9)/16.2(22) at 1500/1800 |
| Continuous Rating kW(PS)/min-1 | 12.2(16.6)/14.7(20) at 1500/1800 |
| Specific Fuel Consumption g/kW-h(g/PS-h) | 245(180) (at rated output) |
| Ambient Condition | 25℃, 750mmHg, 30% |
| Engine Dry Weight (kg) | approx. 155 |
| Alternator Brand | BOBIG |
|---|---|
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-164C |
| Alternator Rated Power | 10kw/13kva |
| Rated Voltage (V) | 230v/400v |
| Rated Frequency | 50hz |
| Connecting Type | 3 Phase and 4 W |
| Number of Bearing | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H class |
| Telephone Influence Factor (TIF) | ≤50 |
| THF | ≤2% |
| Voltage Regulation, Steady State | ≤±1% |
| Transient State Voltage | ≤-15%～+20% |
